Technical Parts Sheets Rolex Watch Movement calibres Information Data Repairs

USB stick loaded with technical parts sheets covering over 80 Rolex movement calibres, ready to open and print in PDF format.

⭐ At a glance

📦 Supplied on a USB memory stick

Format: PDF documents, easily opened and printed

Brand: Rolex

✔️ Condition: New

🔧 What it does & how to use

This is a reference resource for anyone servicing or sourcing parts for Rolex movements — ideal for professional watchmakers, repairers, and hobbyists who need accurate technical data at the bench. Each PDF sheet sets out the parts breakdown for a specific calibre, helping you identify and order the correct components and cross-check details during a repair.

• Load the data: plug the USB stick into a computer and open the folder of PDF sheets.
• Find your calibre: locate the sheet matching the movement you're working on from the included range.
• Print or view on screen: print the sheet for bench use or keep it open on screen while you work.
• Use for sourcing parts: reference the parts breakdown to identify and order the correct components for the repair.

Movements covered include: 72A, 72B, 190, 191, 192, 193, 280, 281, 282, 635, 645, 650, 651, 722.1, 727, 750, 765, 775, 1000, 1030, 1035, 1036, 1036GMT, 1040, 1055, 1065, 1065GMT, 1066, 1066M, 1100, 1120, 1130, 1135, 1160, 1161, 1165, 1166, 1200, 1210, 1215, 1220, 1225, 1240, 1300, 1310, 1315, 1400, 1401, 1520, 1525, 1530, 1535, 1555, 1556, 1560, 1565, 1565GMT, 1570, 1575, 1575GMT, 1580, 1600, 1601, 1602, 1800, 2030, 2035, 2130, 2135, 2230, 2235, 3000, 3035, 3055, 3075, 3085, 3130, 3135, 3175, 3185, 4030, 4130, 5035, 5055, 6620, and 7040.
