Case Back Screws, Slot Head — 35 sizes in one listing. Select yours from the menu.
⭐ At a glance
✅ Options: 35 sizes — full list below
📦 Included: 5× your chosen size
✔️ Condition: new
They come in domed head and straight head please choose correctly.
✅ Sizes — select yours:
- Thread Diameter x Overall length x Head Diameter
Straight Head sizes:
- Ø0.70 x 1.80 x Ø1.50mm Straight Head
- Ø0.70 x 2.20 x Ø1.50mm Straight Head
- Ø0.80 x 1.80 x Ø1.50mm Straight Head
- Ø0.80 x 2.20 x Ø1.50mm Straight Head
- Ø0.90 x 1.80 x Ø1.50mm Straight Head
- Ø0.90 x 2.20 x Ø1.50mm Straight Head
- Ø1.00 x 1.80 x Ø1.50mm Straight Head
- Ø1.00 x 2.00 x Ø1.80mm Straight Head
- Ø1.00 x 2.00 x Ø2.30mm Straight Head
- Ø1.00 x 2.50 x Ø2.60mm Straight Head
- Ø1.10 x 1.80 x Ø1.50mm Straight Head
- Ø1.10 x 2.00 x Ø1.80mm Straight Head
- Ø1.10 x 2.00 x Ø2.30mm Straight Head
- Ø1.10 x 2.50 x Ø2.60mm Straight Head
- Ø1.20 x 1.80 x Ø1.50mm Straight Head
- Ø1.20 x 2.00 x Ø1.80mm Straight Head
- Ø1.20 x 2.00 x Ø2.30mm Straight Head
- Ø1.20 x 2.50 x Ø2.60mm Straight Head
Domed Head sizes:
- Ø1.00 x 1.50 x Ø1.40mm Domed Head
- Ø1.00 x 2.00 x Ø1.60mm Domed Head
- Ø1.00 x 2.20 x Ø1.60mm Domed Head
- Ø1.00 x 2.50 x Ø1.80mm Domed Head
- Ø1.00 x 2.70 x Ø1.80mm Domed Head
- Ø1.20 x 1.60 x Ø1.50mm Domed Head
- Ø1.20 x 2.00 x Ø1.50mm Domed Head
- Ø1.20 x 2.40 x Ø2.00mm Domed Head
- Ø1.20 x 2.80 x Ø2.20mm Domed Head
- Ø1.20 x 3.20 x Ø2.50mm Domed Head
- Ø1.20 x 3.60 x Ø2.30mm Domed Head
- Ø1.40 x 1.80 x Ø2.00mm Domed Head
- Ø1.40 x 2.20 x Ø2.00mm Domed Head
- Ø1.40 x 2.60 x Ø2.50mm Domed Head
- Ø1.40 x 2.80 x Ø2.50mm Domed Head
- Ø1.40 x 3.00 x Ø2.20mm Domed Head
- Ø1.40 x 3.30 x Ø2.20mm Domed Head
Reading the sizes: thread Ø × length × head Ø — e.g. Ø1.00 x 2.00 x Ø1.80mm is a 1.00mm thread, 2.00mm long, with a 1.80mm head. Straight Head = flat top; Domed Head = rounded top.
⚠️ Please check the size against the part you're replacing before ordering — measure the original if unsure.
